| Read the code pattern | CCD |
| The light source type | LED (630NM) |
| Light source | 265 LUX (130nm) |
| Scanning mode | Image type scanning |
| Accuracy | ≥5mil |
| The printing contrast | ≥30% |
| The highest power | 1.33W |
| working voltage | (3.3V~4.2V)±5% |
| maximum current | 350mA |
| Transmission mode | Cable transmission |
| Profound Angle | 34 ° 46 ° V x H level (vertical) |
| scan Angle | 360°, ±65°, ±60° |
| Scanning performance (scanning depth of field) | (1mil=0.0254mm)EAN13 (13mil) 70mm-270mm Code39(6mil) 55mm-140mm Code39(31mil) 200mm -300mm Code39(17mil) 80mm – 290mm QR Code(15mil) 30mm – 165mm |
| Decoding ability | 1D Codabar, Codablock A, Codablock F, Code 11, Code32, Code 39, Code 93, Code 128, EAN-13 & EAN-8, Full ASCII Code39, GS1 Data Bar, Industrial 2 of 5, Interleaved 2 of 5, ISBN / ISSN, Matrix 2 of 5, MSI / Plessey, UPC-A/ UPC-E |
| prompt | buzzer, LED lights |
| Scanning mode | handheld button trigger scanning |
| Scanning speed | 200/s |
| support interface | USB interface |
